MQTT Deep Dive: Giao Thức Messaging Cho IoT

{org}/{site}/{zone}/{device-type}/{device-id}/{data-type}

acme/factory-berlin/zone-a/temperature-sensor/ts-0042/telemetry
acme/factory-berlin/zone-a/temperature-sensor/ts-0042/status
acme/factory-berlin/zone-a/temperature-sensor/ts-0042/alerts
acme/factory-berlin/zone-b/motor/motor-007/telemetry

# Device publishes telemetry (device → cloud)
devices/{device-id}/telemetry

# Cloud publishes commands (cloud → device)
devices/{device-id}/commands

# Device publishes command responses
devices/{device-id}/commands/response

# Requester publishes với correlation ID
requests/{target-device}/rpc
  payload: { "id": "req-123", "method": "getConfig", "replyTo": "responses/requester-1" }

# Target publishes response đến replyTo topic
responses/requester-1
  payload: { "id": "req-123", "result": { "interval": 60, "threshold": 35 } }

# Standard subscription — tất cả subscribers nhận mọi message
devices/+/telemetry

# Shared subscription — messages phân phối round-robin
$share/processing-group/devices/+/telemetry

❌ devices/telemetry          → Không có device ID — không filter được theo thiết bị
❌ ts-0042                     → Không có hierarchy — không thể dùng wildcards
❌ /devices/ts-0042/data      → Leading slash tạo level trống
❌ devices/TS_0042/Data       → Casing không nhất quán
❌ devices/ts-0042            → Một topic cho mọi thứ — không tách được telemetry khỏi commands

class IdempotentProcessor {
  private processed = new Set<string>();
  private maxSetSize = 100_000;

  process(message: { messageId: string; payload: any }): boolean {
    // Bỏ qua nếu đã xử lý
    if (this.processed.has(message.messageId)) {
      console.log(`Duplicate bỏ qua: ${message.messageId}`);
      return false;
    }

    // Loại bỏ entries cũ nhất nếu set quá lớn
    if (this.processed.size >= this.maxSetSize) {
      const first = this.processed.values().next().value;
      this.processed.delete(first);
    }

    this.processed.add(message.messageId);
    return true; // Xử lý message này
  }
}

Publisher → PUBLISH QoS 2 → Broker → Subscriber (subscribed QoS 1) → delivers ở QoS 1

import mqtt from 'mqtt';

// MQTT v5.0 — kiểm soát session chi tiết
const client = mqtt.connect('mqtt://broker:1883', {
  protocolVersion: 5,
  clientId: 'sensor-ts-0042',

  // Clean Start: true = bỏ session hiện tại, false = resume
  clean: false,

  properties: {
    // Session Expiry Interval: broker giữ session bao lâu sau khi ngắt kết nối
    // 0 = xóa ngay (tương đương clean=true trong v3.1.1)
    // 4294967295 (0xFFFFFFFF) = không bao giờ hết hạn
    sessionExpiryInterval: 3600, // Giữ session 1 giờ sau khi ngắt kết nối
  },
});

client.on('connect', (connack) => {
  if (connack.sessionPresent) {
    console.log('Đã resume session hiện tại — subscriptions còn nguyên');
    // Không cần re-subscribe — broker nhớ
  } else {
    console.log('Session mới — subscribing topics');
    client.subscribe('devices/ts-0042/commands', { qos: 1 });
  }
});

client.publish('devices/ts-0042/commands', JSON.stringify({
  action: 'recalibrate',
  timestamp: Date.now(),
}), {
  qos: 1,
  properties: {
    messageExpiryInterval: 300, // Hết hạn sau 5 phút
  },
});

// Nếu device kết nối lại sau 10 phút, command này đã biến mất
// — recalibrate với parameters cũ cũng chẳng có ý nghĩa

# /etc/mosquitto/conf.d/tls.conf

# Tắt plaintext listener
# listener 1883

# TLS listener
listener 8883
cafile /etc/mosquitto/certs/ca.crt
certfile /etc/mosquitto/certs/server.crt
keyfile /etc/mosquitto/certs/server.key
tls_version tlsv1.3

# Yêu cầu client certificates (mTLS)
require_certificate true
use_identity_as_username true

# /etc/mosquitto/conf.d/auth.conf
allow_anonymous false
password_file /etc/mosquitto/passwd

# Tạo password file
mosquitto_passwd -c /etc/mosquitto/passwd sensor-ts-0042
# Nhập password khi được hỏi

# Tạo CA (Certificate Authority)
openssl genrsa -out ca.key 4096
openssl req -x509 -new -nodes -key ca.key -sha256 -days 3650 \
  -out ca.crt -subj "/CN=IoT CA"

# Tạo device certificate
openssl genrsa -out device-ts-0042.key 2048
openssl req -new -key device-ts-0042.key \
  -out device-ts-0042.csr -subj "/CN=sensor-ts-0042"
openssl x509 -req -in device-ts-0042.csr -CA ca.crt -CAkey ca.key \
  -CAcreateserial -out device-ts-0042.crt -days 365 -sha256

import mqtt from 'mqtt';
import jwt from 'jsonwebtoken';

// Tạo JWT ngắn hạn cho device authentication
function getDeviceToken(deviceId: string): string {
  return jwt.sign(
    {
      sub: deviceId,
      permissions: ['publish:devices/+/telemetry', 'subscribe:devices/+/commands'],
      iat: Math.floor(Date.now() / 1000),
    },
    process.env.JWT_SECRET!,
    { expiresIn: '1h' }
  );
}

// Device kết nối với JWT làm password
const client = mqtt.connect('mqtts://broker:8883', {
  clientId: 'sensor-ts-0042',
  username: 'sensor-ts-0042',
  password: getDeviceToken('sensor-ts-0042'),
});

# /etc/mosquitto/conf.d/acl.conf
acl_file /etc/mosquitto/acl

# /etc/mosquitto/acl — Access Control List
# Sensors chỉ có thể publish đến topics của mình
user sensor-ts-0042
topic write devices/sensor-ts-0042/telemetry
topic write devices/sensor-ts-0042/status
topic read devices/sensor-ts-0042/commands

# Dashboard users có thể đọc mọi thứ nhưng không ghi
user dashboard-user
topic read devices/#

# Admin có thể làm mọi thứ
user admin
topic readwrite #

# ACL dựa trên pattern (dynamic theo client)
pattern write devices/%c/telemetry
pattern read devices/%c/commands

# EMQX hỗ trợ ACL rules qua API
curl -X POST http://localhost:18083/api/v5/authorization/sources/built_in_database/rules/users \
  -H "Content-Type: application/json" \
  -d '{
    "username": "sensor-ts-0042",
    "rules": [
      {"action": "publish", "topic": "devices/sensor-ts-0042/telemetry", "permission": "allow"},
      {"action": "publish", "topic": "devices/sensor-ts-0042/status", "permission": "allow"},
      {"action": "subscribe", "topic": "devices/sensor-ts-0042/commands", "permission": "allow"},
      {"action": "all", "topic": "#", "permission": "deny"}
    ]
  }'

# docker-compose.emqx-cluster.yml
version: "3.8"

services:
  emqx1:
    image: emqx/emqx:5.5
    container_name: emqx1
    environment:
      - EMQX_NODE_NAME=emqx@emqx1
      - EMQX_CLUSTER__DISCOVERY_STRATEGY=static
      - EMQX_CLUSTER__STATIC__SEEDS=[emqx@emqx1,emqx@emqx2,emqx@emqx3]
    ports:
      - "1883:1883"    # MQTT
      - "8083:8083"    # WebSocket
      - "8883:8883"    # MQTT/TLS
      - "18083:18083"  # Dashboard
    networks:
      - emqx-net

  emqx2:
    image: emqx/emqx:5.5
    container_name: emqx2
    environment:
      - EMQX_NODE_NAME=emqx@emqx2
      - EMQX_CLUSTER__DISCOVERY_STRATEGY=static
      - EMQX_CLUSTER__STATIC__SEEDS=[emqx@emqx1,emqx@emqx2,emqx@emqx3]
    ports:
      - "1884:1883"
    networks:
      - emqx-net

  emqx3:
    image: emqx/emqx:5.5
    container_name: emqx3
    environment:
      - EMQX_NODE_NAME=emqx@emqx3
      - EMQX_CLUSTER__DISCOVERY_STRATEGY=static
      - EMQX_CLUSTER__STATIC__SEEDS=[emqx@emqx1,emqx@emqx2,emqx@emqx3]
    ports:
      - "1885:1883"
    networks:
      - emqx-net

  haproxy:
    image: haproxy:2.8
    container_name: mqtt-lb
    ports:
      - "1880:1883"
    volumes:
      - ./haproxy.cfg:/usr/local/etc/haproxy/haproxy.cfg:ro
    depends_on:
      - emqx1
      - emqx2
      - emqx3
    networks:
      - emqx-net

networks:
  emqx-net:
    driver: bridge

# haproxy.cfg
global
    log stdout format raw local0

defaults
    mode tcp
    timeout connect 5s
    timeout client 120s
    timeout server 120s

frontend mqtt_frontend
    bind *:1883
    default_backend mqtt_backend

backend mqtt_backend
    balance leastconn
    # Sticky sessions theo client IP — quan trọng cho MQTT persistent connections
    stick-table type ip size 200k expire 30m
    stick on src

    server emqx1 emqx1:1883 check inter 5s fall 3 rise 2
    server emqx2 emqx2:1883 check inter 5s fall 3 rise 2
    server emqx3 emqx3:1883 check inter 5s fall 3 rise 2

docker compose -f docker-compose.emqx-cluster.yml up -d

# Kiểm tra trạng thái cluster
docker exec emqx1 emqx ctl cluster status
# Cluster status: running
# Node: emqx@emqx1 (running)
# Node: emqx@emqx2 (running)
# Node: emqx@emqx3 (running)

# docker-compose.hivemq-cluster.yml
version: "3.8"
services:
  hivemq1:
    image: hivemq/hivemq-ce:latest
    container_name: hivemq1
    environment:
      - HIVEMQ_CLUSTER_TRANSPORT_TYPE=TCP
    ports:
      - "1883:1883"
      - "8080:8080"
    networks:
      - hivemq-net

  hivemq2:
    image: hivemq/hivemq-ce:latest
    container_name: hivemq2
    environment:
      - HIVEMQ_CLUSTER_TRANSPORT_TYPE=TCP
    ports:
      - "1884:1883"
    networks:
      - hivemq-net

networks:
  hivemq-net:
    driver: bridge

// Không có topic alias — gửi full topic string mỗi lần
client.publish('acme/factory-berlin/zone-a/temperature-sensor/ts-0042/telemetry', data);
// Overhead: 67 bytes topic mỗi message

// Có topic alias — gửi alias number sau message đầu tiên
const client = mqtt.connect('mqtts://broker:8883', {
  protocolVersion: 5,
  properties: {
    topicAliasMaximum: 100, // Hỗ trợ tới 100 aliases
  },
});

// PUBLISH đầu gửi full topic + gán alias
// Các PUBLISH sau chỉ gửi alias (2 bytes thay vì 67)

import mqtt from 'mqtt';

class MqttConnectionPool {
  private connections: mqtt.MqttClient[] = [];
  private roundRobinIndex = 0;

  constructor(brokerUrl: string, poolSize: number = 5) {
    for (let i = 0; i < poolSize; i++) {
      const client = mqtt.connect(brokerUrl, {
        clientId: `backend-worker-${i}`,
        clean: true,
      });
      this.connections.push(client);
    }
  }

  // Round-robin publish giữa các connections
  publish(topic: string, payload: string, opts?: mqtt.IClientPublishOptions): void {
    const client = this.connections[this.roundRobinIndex];
    client.publish(topic, payload, opts || {});
    this.roundRobinIndex = (this.roundRobinIndex + 1) % this.connections.length;
  }

  // Tất cả connections subscribe (cho shared subscriptions)
  subscribeAll(topic: string, opts?: mqtt.IClientSubscribeOptions): void {
    for (const client of this.connections) {
      client.subscribe(topic, opts || {});
    }
  }
}

// 5 connections xử lý publishing trên nhiều topics
const pool = new MqttConnectionPool('mqtts://broker:8883', 5);

pool.publish('factory/zone-a/aggregated', JSON.stringify(data));

# prometheus.yml
scrape_configs:
  - job_name: 'emqx'
    metrics_path: '/api/v5/prometheus/stats'
    static_configs:
      - targets: ['emqx1:18083', 'emqx2:18083', 'emqx3:18083']
    # Authentication cho EMQX dashboard API
    basic_auth:
      username: admin
      password: public

# Connected clients theo thời gian
emqx_connections_count

# Message throughput (messages mỗi giây)
rate(emqx_messages_received_total[5m])

# QoS 1/2 inflight messages
emqx_messages_qos1_inflight + emqx_messages_qos2_inflight

# Subscription count
emqx_suboptions_count

const monitor = mqtt.connect('mqtt://broker:1883');

monitor.subscribe('$SYS/#');

monitor.on('message', (topic, message) => {
  const value = message.toString();

  switch (topic) {
    case '$SYS/broker/clients/connected':
      console.log(`Connected clients: ${value}`);
      break;
    case '$SYS/broker/messages/received':
      console.log(`Tổng messages nhận: ${value}`);
      break;
    case '$SYS/broker/load/messages/received/1min':
      console.log(`Messages/phút: ${value}`);
      break;
    case '$SYS/broker/heap/current':
      console.log(`Heap memory: ${(parseInt(value) / 1024 / 1024).toFixed(1)} MB`);
      break;
  }
});

import mqtt from 'mqtt';

async function checkBrokerHealth(brokerUrl: string): Promise<{
  status: 'healthy' | 'degraded' | 'down';
  latencyMs: number;
  details: string;
}> {
  return new Promise((resolve) => {
    const start = Date.now();
    const testTopic = `health-check/${Date.now()}`;
    const timeout = setTimeout(() => {
      resolve({ status: 'down', latencyMs: -1, details: 'Connection timeout' });
    }, 5000);

    const client = mqtt.connect(brokerUrl, {
      clientId: `health-check-${Date.now()}`,
      connectTimeout: 5000,
    });

    client.on('connect', () => {
      client.subscribe(testTopic, { qos: 1 });

      client.on('message', () => {
        const latency = Date.now() - start;
        clearTimeout(timeout);
        client.end();

        resolve({
          status: latency < 100 ? 'healthy' : 'degraded',
          latencyMs: latency,
          details: `Round-trip: ${latency}ms`,
        });
      });

      // Publish và expect nhận lại message của mình
      client.publish(testTopic, 'ping', { qos: 1 });
    });

    client.on('error', (err) => {
      clearTimeout(timeout);
      client.end();
      resolve({ status: 'down', latencyMs: -1, details: err.message });
    });
  });
}

// Sử dụng
const health = await checkBrokerHealth('mqtt://broker:1883');
console.log(`Broker: ${health.status} (${health.latencyMs}ms)`);

import mqtt, { MqttClient, IClientOptions } from 'mqtt';

interface DeviceConfig {
  deviceId: string;
  brokerUrl: string;
  username?: string;
  password?: string;
  caCert?: Buffer;
  clientCert?: Buffer;
  clientKey?: Buffer;
}

class MqttDeviceClient {
  private client: MqttClient;
  private deviceId: string;

  constructor(config: DeviceConfig) {
    this.deviceId = config.deviceId;

    const options: IClientOptions = {
      clientId: config.deviceId,
      clean: false, // Persistent session
      reconnectPeriod: 5000, // Retry mỗi 5 giây
      connectTimeout: 10000,
      keepalive: 60, // Gửi PINGREQ mỗi 60 giây

      // Last Will and Testament
      will: {
        topic: `devices/${config.deviceId}/status`,
        payload: Buffer.from(JSON.stringify({
          status: 'offline',
          timestamp: Date.now(),
        })),
        qos: 1,
        retain: true,
      },
    };

    // Thêm auth
    if (config.username) {
      options.username = config.username;
      options.password = config.password;
    }

    // Thêm TLS
    if (config.caCert) {
      options.ca = config.caCert;
      options.cert = config.clientCert;
      options.key = config.clientKey;
      options.rejectUnauthorized = true;
    }

    this.client = mqtt.connect(config.brokerUrl, options);
    this.setupEventHandlers();
  }

  private setupEventHandlers(): void {
    this.client.on('connect', () => {
      console.log(`[${this.deviceId}] Đã kết nối broker`);

      // Publish online status (retained)
      this.client.publish(
        `devices/${this.deviceId}/status`,
        JSON.stringify({ status: 'online', timestamp: Date.now() }),
        { qos: 1, retain: true }
      );

      // Subscribe commands
      this.client.subscribe(`devices/${this.deviceId}/commands`, { qos: 1 });
    });

    this.client.on('message', (topic, message) => {
      try {
        const payload = JSON.parse(message.toString());
        this.handleCommand(payload);
      } catch (err) {
        console.error(`[${this.deviceId}] Message không hợp lệ trên ${topic}:`, err);
      }
    });

    this.client.on('reconnect', () => {
      console.log(`[${this.deviceId}] Đang kết nối lại...`);
    });

    this.client.on('error', (err) => {
      console.error(`[${this.deviceId}] Lỗi:`, err.message);
    });

    this.client.on('offline', () => {
      console.log(`[${this.deviceId}] Offline`);
    });
  }

  publishTelemetry(data: Record<string, number>): void {
    this.client.publish(
      `devices/${this.deviceId}/telemetry`,
      JSON.stringify({ ...data, timestamp: Date.now() }),
      { qos: 0 } // Telemetry: QoS 0 là đủ
    );
  }

  publishAlert(alert: { type: string; message: string; severity: string }): void {
    this.client.publish(
      `devices/${this.deviceId}/alerts`,
      JSON.stringify({ ...alert, timestamp: Date.now() }),
      { qos: 1 } // Alerts: QoS 1 — không được mất
    );
  }

  private handleCommand(payload: any): void {
    console.log(`[${this.deviceId}] Command nhận được:`, payload);

    switch (payload.action) {
      case 'recalibrate':
        // ... thực hiện recalibration
        break;
      case 'updateConfig':
        // ... áp dụng configuration mới
        break;
      case 'reboot':
        // ... lên lịch graceful reboot
        break;
    }

    // Acknowledge command
    this.client.publish(
      `devices/${this.deviceId}/commands/response`,
      JSON.stringify({
        commandId: payload.id,
        status: 'executed',
        timestamp: Date.now(),
      }),
      { qos: 1 }
    );
  }

  async shutdown(): Promise<void> {
    // Publish offline status trước khi ngắt kết nối
    this.client.publish(
      `devices/${this.deviceId}/status`,
      JSON.stringify({ status: 'offline', timestamp: Date.now() }),
      { qos: 1, retain: true }
    );

    return new Promise((resolve) => {
      this.client.end(false, () => {
        console.log(`[${this.deviceId}] Đã ngắt kết nối gracefully`);
        resolve();
      });
    });
  }
}

// Sử dụng
const device = new MqttDeviceClient({
  deviceId: 'sensor-ts-0042',
  brokerUrl: 'mqtts://broker.example.com:8883',
  username: 'sensor-ts-0042',
  password: process.env.DEVICE_TOKEN,
});

// Publish telemetry mỗi 5 giây
setInterval(() => {
  device.publishTelemetry({
    temperature: 23.5 + Math.random() * 2,
    humidity: 65 + Math.random() * 5,
  });
}, 5000);

// Graceful shutdown
process.on('SIGTERM', async () => {
  await device.shutdown();
  process.exit(0);
});

# mqtt_device.py
import json
import time
import ssl
import paho.mqtt.client as mqtt

class MqttDeviceClient:
    def __init__(self, device_id: str, broker_host: str, broker_port: int = 8883):
        self.device_id = device_id
        self.client = mqtt.Client(
            client_id=device_id,
            protocol=mqtt.MQTTv5,
            callback_api_version=mqtt.CallbackAPIVersion.VERSION2,
        )

        # Last Will and Testament
        self.client.will_set(
            topic=f"devices/{device_id}/status",
            payload=json.dumps({"status": "offline", "timestamp": time.time()}),
            qos=1,
            retain=True,
        )

        # Cấu hình TLS
        self.client.tls_set(
            ca_certs="/etc/mqtt/ca.crt",
            certfile=f"/etc/mqtt/{device_id}.crt",
            keyfile=f"/etc/mqtt/{device_id}.key",
            tls_version=ssl.PROTOCOL_TLSv1_2,
        )

        # Callbacks
        self.client.on_connect = self._on_connect
        self.client.on_message = self._on_message
        self.client.on_disconnect = self._on_disconnect

        # Kết nối với auto-reconnect
        self.client.connect(broker_host, broker_port, keepalive=60)

    def _on_connect(self, client, userdata, flags, reason_code, properties):
        print(f"[{self.device_id}] Đã kết nối: {reason_code}")

        # Publish online status
        client.publish(
            f"devices/{self.device_id}/status",
            json.dumps({"status": "online", "timestamp": time.time()}),
            qos=1,
            retain=True,
        )

        # Subscribe commands
        client.subscribe(f"devices/{self.device_id}/commands", qos=1)

    def _on_message(self, client, userdata, msg):
        try:
            payload = json.loads(msg.payload.decode())
            print(f"[{self.device_id}] Command: {payload}")
            self._handle_command(payload)
        except json.JSONDecodeError:
            print(f"[{self.device_id}] JSON không hợp lệ trên {msg.topic}")

    def _on_disconnect(self, client, userdata, flags, reason_code, properties):
        print(f"[{self.device_id}] Ngắt kết nối: {reason_code}")

    def _handle_command(self, payload: dict):
        action = payload.get("action")
        if action == "recalibrate":
            pass  # Thực hiện recalibration
        elif action == "updateConfig":
            pass  # Áp dụng configuration mới

        # Acknowledge
        self.client.publish(
            f"devices/{self.device_id}/commands/response",
            json.dumps({
                "commandId": payload.get("id"),
                "status": "executed",
                "timestamp": time.time(),
            }),
            qos=1,
        )

    def publish_telemetry(self, data: dict):
        self.client.publish(
            f"devices/{self.device_id}/telemetry",
            json.dumps({**data, "timestamp": time.time()}),
            qos=0,
        )

    def start(self):
        self.client.loop_start()

    def stop(self):
        self.client.publish(
            f"devices/{self.device_id}/status",
            json.dumps({"status": "offline", "timestamp": time.time()}),
            qos=1,
            retain=True,
        )
        self.client.loop_stop()
        self.client.disconnect()


# Sử dụng
device = MqttDeviceClient("sensor-ts-0042", "broker.example.com")
device.start()

try:
    while True:
        device.publish_telemetry({
            "temperature": 23.5,
            "humidity": 65.0,
        })
        time.sleep(5)
except KeyboardInterrupt:
    device.stop()

❌ Tất cả thiết bị kết nối với clientId "my-device"
   → Broker ngắt kết nối client trước khi client mới kết nối cùng ID!

✅ Mỗi thiết bị có clientId riêng: "sensor-ts-0042", "sensor-ts-0043"

❌ client.subscribe('#')   → Nhận TẤT CẢ messages trên toàn bộ broker

✅ client.subscribe('factory/zone-a/+/telemetry')   → Chỉ những gì bạn cần

❌ Device publishes status khi connect, subscriber mới bỏ lỡ
   → Dashboard hiển thị "unknown" cho đến khi device publish status tiếp

✅ Device publishes status với retain=true
   → Subscriber mới lập tức nhận last known status

❌ keepalive=0 (tắt) → Broker không phát hiện được dead connections
   → Ghost sessions tích lũy, chiếm broker memory

✅ keepalive=60 → Broker expect PINGREQ trong 1.5× keepalive (90s)
   → Dead connections tự động phát hiện và dọn dẹp

❌ Một lần connect → connection fail → thiết bị im lặng mãi

✅ Exponential backoff reconnection:
   Lần 1: chờ 1s → Lần 2: chờ 2s → Lần 3: chờ 4s → ... → max 60s
